Sensor

1/4" progressive scan CMOS

Video Standard

Tri-codec: M-JPEG, MPEG-4, H.264

Secondary Channel

Supports dual streaming

Data Rate

Stream 1/2/3GPP, multi-level configurability

Dynamic Control

Active bandwidth management, activity adaptive streaming

Sensor Matrix

640x480

Resolution & Frame Rate

640x480 up to 60 fps

Day/Night Illumination

NC120: Mechanical ICR

Channel Division

1, 4CH; 16CH per WebVUer, sequentia

Imaging

Color Contour: Brightness, saturation, sharpness, multi-level configurability

Compression Format

G.711 PCM 64 Kbit/sec, bi-directional audio streaming

Microphone

Built-in x 1, S/N ratio > 58 dB, sensitivity 50~10000 Hz

Audio Input / Output

Mic in x 1, line-out x 1, 3.5 mm phone jack

Zooming

10x digital; fits web browser; 100%

Control

Supports Pelco D scanner (via RS-485)

Sensor In / Alarm Out

In x 1, relay out x 1, terminal block

Device Integration

RS-485 x 1, terminal block

Intelligent Analytics

Video motion detection, tampering detection, loitering detection, audio detection, multi-zone/sensitivity

Triggering Event

Analytics, schedule, I/O, network failure

Triggering Reaction

SMS, snapshot, local/remote recording, email, FTP, alarm output, ComproView notification

SDK

Yes

Local Storage

microSD/SDHC slot, up tp 32GB (card not included)

Format

AVI (audio incl. ), by events or schedule; JPEG, file name format customizable

Playback

Playback by event type (motion, I/O, schedule, audio), auto overwriting; never erase

Protocols

3GPP, ARP, DDNS, DHCP, DNS, FTP, HTTP, ICMP/IPv4, IGP, NTP, PPPoE, QoS, RSP, RTSP, SMTP, SSL, TCP/IP, UDP, UPnP

Ethernet

10/100 Base-T, autosensing, RJ-45, LED status indicator

User Group

2 levels, unlimited users, ID/password protected, max 10 simultaneous users

Encryption

WEP, WPA-PSK, WPA2-PSK (via WiFi connection)

Diagnostics

Auto connectivity diagnosis, auto bandwidth detection, iWizard

Mobile Surveillance

M-JPEG, 3GPP over Android, BlackBerry, iPhone, Windows Mobile (features vary)

Web Surveillance

WebVUer 16CH over Internet Explorer, Chrome, Firefox, Safari (features vary)

Advanced Surveillance

ComproView 32CH surveillance system

Unit Configuration

Rebooting, factory default, date/time synchronization, user profile management, firmware upgrade, OSD, date/time stamp, multilingual UI

User Authentication

ID, password

Firmware

HTTP mode, remote update

OSD

Text or image overlay, 4 locations

Language

Chinese Traditional, Chinese Simplified, German, Spanish, English, Japanese, Portuguese, Russian, Turkish, Ukrainian, Arabic

Regulatory

CE, FCC

Lens Type & Mounting

C/CS mount (HD, f 4.0 mm, F1.5, Fixed iris, FOV 48º(H))

Casing

Box, white, heat dissipating

Dimension (HxWxD)

185 x 60 x 60 mm (connectors incl.)

Weight (Net)

350 g (0.77 lb.)

Input Voltage

DC 12V, AC 24V, or PoE, terminal block, power LED indicator

Power-over-Ethernet

IEEE 802.3af Class 3

Operating Temperature

Storage Temperature

-10~60ºC / -14~140ºF

Humidity

20~80% RH non-condensing

OS

Microsoft Windows XP SP3, Vista SP1, 7 (x86/x64)

Processor

Intel 1.7 GHz, 512 MB RAM

Web Browser

Microsoft Internet Explorer 6.0 or above, non-IE browsers require 3rd-party VLC codec

MicroSD/SDHC card, camera bracket
