2 Port 4K UltraHD Dual DisplayPort™ 1.2 KVM Switch
2 Port 4K UltraHD Dual DisplayPort™ 1.2 KVM Switch 2 Port 4K UltraHD Dual DisplayPort™ 1.2 KVM Switch

2 Port 4K UltraHD Dual DisplayPort™ 1.2 KVM Switch

DP1.2-MUX2-MC-USB

สลับใช้คอมฯ 2 เครื่อง ด้วยจอ 4K แบบ Dual DisplayPort™ 1.2 และ คีย์บอร์ดเมาส์ แบบ USB, อุปกรณ์ USB2.0, ลำโพง, ไมค์ ชุดเดียวกัน

รายละเอียดเพิ่มเติม

รับประกัน 3 ปีเต็ม



รับประกัน 3 ปี

Spec Sheet

สลับใช้คอมฯ 2 เครื่อง ด้วยจอ 4K แบบ Dual DisplayPort™ 1.2 และ คีย์บอร์ดเมาส์ แบบ USB, อุปกรณ์ USB2.0, ลำโพง, ไมค์ ชุดเดียวกัน

คุณสมบัติ

Video

  • 2x DisplayPort™ 1.2 on input and output side
  • E-DDC support
  • Colour depth: 24 Bit

Exemplary resolutions:

  • 4096 × 2160 @ 60 Hz (4K/60 Hz)
  • 3840 × 2160 @ 60 Hz (Ultra-HD/60 Hz)
  • 2560 × 1600 @ 60 Hz
  • 1920 × 1200 @ 60 Hz
  • 2048 × 2048 @ 60 Hz (2K x 2K)

More standardized resolutions within the max. pixel rate and refresh rate between 24 and 120 Hz possible.

Device

  • Accesses the computer's standard interfaces only
  • Switching via push button, keyboard hotkeys or serial device connected to the service interface
  • Requires no software installation
  • Available as desktop and 19" rack mount variant
  • Internal power supply
  • Aluminium housing for best interference resistance
  • Hot-pluggable

Signals

  • USB Keyboard / Mouse
  • USB 2.0 transparent
  • Audio

System upgrade

  • Flash upgrade at device

Design

  • Available as desktop (DT) or rack mount (RM) variant

Peripheral connections

  • Available for USB connections
