Camera control unit - Sony
CCU-100S
The CCU-100S is a Sony camera control unit which is typically part of a live television broadcast "chain." It is responsible for powering the professional video camera, handling signals sent over the All in one camera cable (CB-49) to and from the camera and can be used to remotely control various camera parameters such as iris.
ManualThe CCU-100S is a Sony camera control unit which is typically part of a live television broadcast "chain."
It is responsible for powering the professional video camera, handling signals sent over the All in one camera cable (CB-49) to and from the camera and can be used to remotely control various camera parameters such as iris.
The system simultaneously transmits digital SDI and analogue signals as well as camera control, look back, camera view finder data, tally and intercom call signals between professional cameras and the switcher system.
CCU-100S and AD-2S form an integrated solution that allows you to get things done fast, easy and within budget.
*Required Hardware*: Datavideo MCU-100 or MCU-200
Features
- Camera control unit - Sony
- Connection between CCU-100 and up to 4 AD-2’s to control 4 sony cameras
- Remote control of camera functions
- HD/SD SDI video transmission from digital camera
- Return colour view finder / monitor video
- Return look back video signal
- Two-way headset intercom
- Tally Support
- Power Supply
- Ethernet Port for Remote Control
- Includes: 4 x AD-2S Multi Transmission Adaptor Box, 4 x RMC-240 Remote Controller, 4x HP-3 headphones
Supported functions
- Record and Playback
- Camera User memory functions
- Camera OSD Menu Navigation
- SHORT MARK
- Shutter adjustment
- Iris adjustment
- AWB & ABB functions
- White Balance A, B and Preset functions
- Knee & Bars functions
- Gain adjustment
- RGB / R & B gain and Master Pedestal controls
