KE861D
Dual Monitors DVI KVMR Extender Over LAN with Audio, Mic, RS232, 4 x USB2.0 Port for keyboard, mouse and other USB 2.0 devices High Quality Digital Video Support up to 100M Extension
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:

Dual Monitors DVI KVMR Extender Over LAN with Audio, Mic, RS232, USB Hub
Dual Monitors DVI KVMR Extender Over LAN with Audio, Mic, RS232, 4 x USB2.0 Port for keyboard, mouse and other USB 2.0 devices High Quality Digital Video Support up to 100M Extension
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก


Model | KE861D-TX | KE861D-RX | |
modules | 1 x KE861D-TX (Transmitter Unit) | 1 x KE861D-RX (Receiver unit) | |
PC connections | 1 | - | |
connections | 2 x DVI-D socket 1 x IR Remote "Out" socket 1 x USB port (Type B) 1 x Mi krofon "Out" socket 1 x loudspeaker "in" socket 1 x RJ45 socket (LAN or 1: 1) | 2 x DVI-D socket 1 x IR remote " In" socket 4 x USB port (Type A) 1 x Mi krofon " in" socket 1 x speaker "Out" socket 1 x RJ45 socket (LAN or 1: 1) | |
LEDs | 1 x power (red) 1 x link (green) | ||
switch | 2 x buttons 1 x 3 dip switch | ||
DVI video resolution | up to 1920 x 1200 / 60Hz / Full HD 1080p - 100m (digital) | ||
Operating temperature | 0 - 40 ° C | ||
Storage temperature | -20 - 60 ° C | ||
humidity | 0 - 90% RH, Non- Condensing | ||
mass | 750g | 750g | |
Dimensions (L x W x H) | 120 x 135 x 53.5 mm | ||
casing | Metal | ||
power adapter | 2x 9V, 2A DC Current consumption of the modules at 9V DC: Transmitter approx. 0.5A, receiver approx. 0.4A (monitor, as well as standard keyboard and standard mouse connected). | ||
Approvals | FCC, CE | ||
