Full HD PTZ Conference Camera
CI-21H
Spec sheet- Compact Design with IP Streaming
- Capable of Production Quality Full HD Video Output up to 1080/60p via HDMI, USB3.0 and IP Transmission
- Plug-and-Play Compatibility: USB connectivity to PC and Laptop
- Featuring a 10x Optical Zoom that Delivers Smooth Pan, Tilt, and Zoom-in Performance
- IR Remote Control Included
- Suitable for huddle rooms and small-to-medium conference rooms
Features
EASY IMPLEMENTATION FOR ANY TYPE OF INDOOR SCENARIO
Combining RJ-45, HDMI and USB 3.0 outputs, CI-21H PTZ Camera can be used with AREC Media Stations for Lecture Capture, any Video Conference System (either HW or SW-based), related SW-based Lecture Capture Platform, and even stream to a Live Streaming Service directly.
FULLY ENJOY THE PROFESSIONAL VIDEO QUALITY
With high performance H.264 compression technology, AREC CI-21H provides Full HD quality at up to 1080/60p. Featuring advanced ISP processing algorithms, CI-21H provides vivid images with fantastic color rendition. Low noise CMOS effectively ensure high SNR of camera video.
QUIET AND QUICK PAN/TILT MECHANISM
CI-21H supports 270 degree rotation, a 60 degree tilt range, and 10x zoom with auto focus capability. The pan/tilt/zoom control functions can be performed remotely. Adopting step driving motor mechanism, CI-21H camera works extremely quiet and moves smoothly.
Specifications
| SPEC/ MODEL | CI-21H PTZ Conferencing Camera |
|---|---|
| IMAGE SENSOR | 1/2.8” progressive CMOS |
| MINIMUM ILLUMINATION | 0.5 lux @ F1.8 |
| VIDEO COMPRESSION | H.264 |
| MAX. RESOLUTION | 1920x1080 @ 60fps (IP Streaming) 1920x1080 @ 60fps (HDMI/USB 3.0) |
| VIDEO OUTPUT PORT | HDMI, USB 3.0, RJ-45 (IP Streaming) |
| NETWORK INTERFACE | RJ-45, 100Mbps Ethernet |
| FOCAL LENGTH | 4.7 - 47mm (10x optical zoom) |
| IRIS | F1.6 (wide) / F3.0 (tele) |
| VIEW ANGLE | 60.9° (wide) ~ 6.43° (tele) |
| PAN/TILT ROTATION | -135°~+135°, -30°~+30° |
| PAN/TILT CONTROLLER SPEED | 0.1∼60° / second, 0.1∼30° / second |
| PAN/TILT SPEED (MAX.) | Pan: 60°/ second, Tilt: 30°/ second |
| CONTROL PORT | RS-232 |
| CONTROL PROTOCOL | VISCA/ Pelco-D/ Pelco-P |
| NETWORK PROTOCOL | RTSP, RTMP, ONVIF |
| DIMENSION (L X W X H) | 128.9 x 151.6 x 154.5 mm |
| WEIGHT | 1kg |
