BC-78A
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:

4K60 Multifunction Adjuster, Scaling, seamless, audio
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก

อุปกรณ์ปรับความละเอียดสัญญาณวิดีโอ แบบมัลติฟังก์ชัน รองรับอินพุต/เอาต์พุต HDMI2.0 อย่างละ 1 ช่อง รองรับการปรับความละเอียดขาออกสูงสุดถึง 4K60 4:4:4 ช่วยแก้ปัญหา source ต้นทางไม่สามารถ detect สัญญาณ EDID ได้อย่างมีประสิทธิภาพ
Video | |
Input port | 1* HDMI2.0 |
Input resolution |
640x480, 800x600, 1024x768, 1280x768, 1280x800, 1280x1024, 1360x768, 1366x768, 1440x900, 1400x1050, 1600x1200, 1680x1050, 1920x1200, 720x480 (480p), 720x576 (576p), 1280x720 (720p30), 1280x720 (720p50), 1280x720 (720p60), 1920x1080 (1080p24), 1920x1080 (1080p25), 1920x1080 (1080p30), 1920x1080 (1080p50), 1920x1080 (1080p60), 3840x2160(2160p30),3840x2160 (2160p50), 3840x2160 (2160p60) |
Output port | 1* HDMI2.0 |
Output resolution |
1920x1080 (1080p50), 1920x1080 (1080p60), 3840x2160 (2160p30) , 3840x2160 (2160p50) , 3840x2160 (2160p60) |
Audio | |
Input port | 1x HDMI, 1*3.5mm Analog |
Input audio signal | RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0 |
Output port | 1* HDMI2.0, 1* Analog Audio(3.5mm audio) |
Output audio signal | RAW PCM, 16 bit, 32/44.1/48KHz sps; PCM 2.0 |
Control | |
Front control | Rotate |
IR | IR remote controller |
RS232 | 3-pin Phoenix |
Others | |
Operating temperature | 0 to +45 C (32 to + 113 F) |
Storage temperature | -20 to +70 C (-4 to + 158 F) |
Humidity | 10% to 90% |
Static Protection | Human body discharge mode: ±8kV (air gap discharge)/ ±4kV (contact discharge) |
Power adapter | DC 12 V 1.5 A |
Power consumption | 10W(Max) |
Product size(mm) | 138*85*28 |
Net Weight | 0.5kg |
