HDMI over HDBaseT Slimline Receiver (PSE) with USB and Optical Audio Return
CH-2602RX
HDBaseT 2.0 Receiver can receive uncompressed UHD video and audio that has been transmitted over a single Cat.5e/6/7 cable up to 100m. รับประกัน 3 ปี !!!
รับประกัน 1 ปีเต็ม
This HDBaseT 2.0 Receiver can receive uncompressed UHD video and audio that has been transmitted over a single Cat.5e/6/7 cable up to 100m. It has the added benefit of extending control and communication signals through the built-in Ethernet, USB, RS-232 and IR ports. Independent external digital and analog audio transmission capability gives users the extra convenience of additional audio connections.
รับประกัน 3 ปี !!!
ManualFeatures
- Supports the HDBaseT 2.0 specification over a single Cat.6/7 cable up to 100m/328ft and Cat.5e cable up to 90m/295ft
- HDBaseT 5Play™ convergence: High-Definition (HD) Video and Audio, 100BaseT Ethernet, 48V PoH, and Control (Bi-directional IR/RS-232 pass-through)
- Transmitter (PD) is powered by 48V PoH from the Receiver (PSE)
- HDMI with 3D & 4K@60Hz (YUV 4:2:0) support, DVI 1.0 compatible
- HDCP 2.2 compliant
- 2×USB 2.0 Type A ports
- Supports pass-through of HD audio formats: LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream
- Supports optical audio sampling rates up to 48kHz
- Supports external analog and digital audio extension including support for ARC (Audio Return Channel)
- Supports RS-232 baud rates from 110~115200bps
- Ultra-thin mechanical design
| Inputs | 1x RJ45 [1x HDMI & Propriety Data] 1x TOSLINK [1x OPTICAL 2 Channel LPCM] 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver] |
| Outputs | 1x HDMI [1x Uncompressed AV and Data] 1x RJ45 [1x LAN Serving] 3x 1-Pin Terminal Block [1x Stereo (L/R)] 2x USB Type A [2x Propriety Data] 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter] 3x 1-Pin Terminal Block [1x RS-232] |
| PSU: | 48V/0.83A |
| Dimensions | 183mm [W] x 80mm [D] x 16mm [H] |
| Net Weight | 354g |
Available Transmitter / Receiver
