T740V
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:
All-in-One Conference Bar 4K Camaera & AI Tracking
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก
|
Feature |
Specification |
|
Sensor |
1/2.8 inch, CMOS |
|
Effective Pixels |
20 Megapixels |
|
Signal System |
4K@30fps, 1080P@30fps, 720P@30fps, etc. |
|
Field of View (FOV) |
120° (Diagonal), 110° (Horizontal), 75° (Vertical) |
|
Zoom |
5x Digital Zoom |
|
Pan/Tilt/Zoom (PTZ) |
Electronic PTZ (ePTZ) with mechanical tilt from -10° to +10° |
|
Noise Reduction |
2D & 3D Digital Noise Reduction |
|
Signal-to-Noise Ratio (SNR) |
>55dB |
|
Backlight Compensation |
Supported |
|
Port Type |
Quantity & Description |
|
USB 3.0 |
1x Type-C (female), 1x Type-A (female, for expansion MIC and firmware upgrade) |
|
HDMI |
1x HDMI 2.0 Out, 1x HDMI 2.0 In (plus 1 optional HDMI 2.0 In) |
|
Network (LAN) |
1x RJ45 (10/100/1000M adaptive Ethernet) |
|
Network (MIC) |
1x RJ45 (Connect to expansion mic, POE 802.3at) |
|
Power |
1x DC Power connector (DC 12V) |
|
Wi-Fi |
Built-in, requires external USB expansion |
|
Remote Controller |
Supported |
|
Protocol |
Specification |
|
Connection Type |
USB 3.0 (backward compatible with USB 2.0) |
|
Video Protocol |
UVC 1.1 |
|
Video Compression |
H.265 / H.264 |
|
Audio Protocol |
UAC 1.0 (48K sampling rate) |
|
PTZ Control |
UVC PTZ Support (for EPTZ) |
|
Specification |
Value |
|
Power Supply |
DC 12V / 5A (Max) |
|
Dimensions (L×W×H) |
700mm × 135mm × 110mm (bracket excluded) |
|
Net Weight |
2.5kg |
|
Working Temperature |
0°C ~ 40°C |
|
Storage Temperature |
-40°C ~ 60°C |
|
Installation Methods |
Display placement, wall-mounting, TV mounting |
